Knox PowerWall 3.0

Technical Specifications

• Model: LIO 2.56-IP20
• Battery Type: LiFePO4
• Nominal Voltage: 25.6V
• Nominal Capacity: 100Ah
• Energy: 2560Wh (2.56kWh)
• Pack Mode: 8S1P
• Continuous Discharge Current: 100A
• Charge Cut-off Voltage: 28.8V
• Discharge Cut-off Voltage: 22V
• Maximum Charge Current: 100A
• Maximum Discharge Current: 100A
• Peak Discharge Current: 120A
• Recommended Discharge Current: 50A
• Recommended Depth of Discharge: 80%
• Cycle Life: More than 6000 Cycles (25°C, 0.5C @ 80% DOD)
• Communication: RS485
• Display: LCD
• Mounting: Wall-mounted
• Environmental Specifications
• Charge Temperature: 0°C to +55°C
• Discharge Temperature: -20°C to +60°C
• Optimal Storage Temperature: 5°C to +35°C
• Relative Humidity: 40%–80%
• Ingress Protection: IP20
• Mechanical Specifications
• Terminal: M6
• Dimensions (L × W × H): 350 × 180 × 450 mm
• Weight: 25.1 ± 0.5 kg

Certificate: UN38.3, MSDS
