TIGFOX TB5120 Plus

Technical Specifications

• Model: TB5120 Plus

• Battery Type: LiFePO4

• Nominal Voltage: 51.2V

• Nominal Capacity: 100Ah

• Nominal Energy: 5.12kWh

• Usable Capacity: 4.86kWh (95% DOD)

• Energy: 5120Wh

• Working Voltage Range: 43.2V – 58.4V DC

• Charging Rate: 1C

• Discharge Rate: 1.5C

• Maximum Charge Current: 100A

• Maximum Discharge Current: 150A

• Communication Ports: RS485 / CAN / Dry Contact / RS232

• Installation Type: Wall-Mounted

• Ingress Protection: IP54

• Cycle Life: More than 6000 Cycles (25°C, 60% EOL)

• Design Life: 10 Years (25°C)

• Scalability: Up to 16 Units in Parallel

• Maximum Expandable Capacity: 81.92kWh

• Charging Temperature: 0°C to +50°C

• Discharging Temperature: -20°C to +60°C

• Recommended Storage Temperature: -10°C to +35°C

• Working Humidity: ≤95% RH (Non-Condensing)

• Storage Humidity: ≤85% RH

• Working Altitude: ≤2000m

• Dimensions (L × W × H): 780 × 630 × 68 mm

• Weight: Approximately 49kg

• Installation: Wall-Mounted

• Protection Rating: IP54

• Advanced LiFePO4 battery technology

• High 5.12kWh energy storage capacity

• Ultra-slim 68mm wall-mounted design

• 4.86kWh usable capacity at 95% DOD

• Long lifespan of 6000+ cycles

• High 150A maximum discharge current

• IP54 protection rating

• Compatible with 80% of solar inverters

• Supports up to 16 batteries in parallel

• Maximum expandable capacity of 81.92kWh

• RS485, CAN, Dry Contact, and RS232 communication

• 5-year warranty
